Find the Right Projector Screen: Type, Size, and Material to Consider

• Ceiling-Mounted Pull-Down Screens (Picture B)

Lightweight, affordable, and don’t require power, this screen is easy to install anywhere. With no motor to worry about, it’s low-maintenance and built to last. The only downside is that you’ll need to pull it down by hand each time you use it, which can be a bit inconvenient.

•  Motorized Non-Tensioned Projection Screens (Picture C)

You can use a dedicated remote control, a wall switch, or the 12V trigger to control the screen. They are very convenient and stylish, but they cost more, require a dedicated power supply, and have more components that may eventually fail.

Both manual and motorized retractable screens work well for most uses. However, most of them don’t include side tensioning by default, and this can lead to curling, ripping, or bending over time, which may distort the image. If a flat projection surface is important to you, consider upgrading to a tensioned model and be prepared to pay more.

• Tab-Tensioned Projection Screens (Picture D)

To obtain the best performance out of a retractable screen, you should look for a tab-tensioned one. This type of screen has a system behind it to ensure that the surface is perfectly tight and flat when pulled out, while the whole tensioning system also moves out of the way when the screen is rolled in. Without tensioning, retractable screens tend to have curling and wrinkling, especially noticeable during panning shots.

Once you've picked the screen type, it's time to choose the right size for your projection screen. In most cases, the price difference between a 100-inch and a 120-inch screen is minimal. So it's often worth going as big as your wall allows.

That said, bigger isn’t always better. A larger image also requires a longer viewing distance. If your room is on the smaller side, a more modest screen may actually offer a better experience.

To find the ideal viewing distance, you’ll need to consider the human field of vision. The SMPTE (Society of Motion Picture and Television Engineers) recommends a viewing angle of at least 30°, while THX suggests 40° for a more immersive, cinematic feel.

A simple way to calculate it is:

• For movie watching – screen size × 1.3

For example, a 120-inch screen is ideal when sitting about 156 inches (13 feet) away, or a 100-inch screen at 130 inches (10.8 feet).

• For everyday use – screen size × 1.8

For example, a 120-inch screen works well at a distance of 216 inches (18 feet), or a 100-inch screen at about 180 inches (15 feet).

So when choosing your ideal screen size, be sure to consider your available projection distance. Understanding the relationship between screen size and throw distance is key to getting the best experience. To find exact numbers for your setup, we recommend using the BenQ Projection Distance Calculator

Aside from screen size and aspect ratio, the material of your screen plays a major role in overall image quality.

White is the most common screen color, but other options exist for different viewing environments. For home entertainment, a white screen remains the best choice.

Some screens feature a special coating to boost brightness and enhance HDR effects. However, this often comes at the cost of a narrower viewing angle and the risk of hot spotting, areas on the screen that appear overly bright or unnatural. For most home setups, a screen with even light distribution and no gain is the better choice.

Most projection screens are made of fabric-like materials that reflect light well but block sound. As a result, speakers need to be placed beside or away from the screen. Acoustic screens use a specially woven mesh that allows sound waves to pass through while still maintaining acceptable image quality. This lets you place speakers directly behind the screen, maximizing screen size even in smaller rooms. However, because acoustic materials typically reflect less light, they’re best suited for custom home theaters or darker environments.

Don’t worry. Choosing a projector screen may involve several factors, but making the right choice means years of immersive, high-quality viewing. If you want to dive deeper into projection tech, visit BenQ’s Knowledge Center for more tips and insights.

And don’t forget: your projector and screen work as a team. Consider projection distance, brightness, supported aspect ratios, and native resolution to get the best match for your setup.

Choose the right screen based on your space, lighting conditions, projection distance, and budget flexibility.



Here’s to creating your ideal home theater. Enjoy the journey!
